ID # 24532570 2023 Kawasaki KLX230 S Non-ABS
Take to the playing field by storm with nimble dual-sport performance that's ready to conquer both on- and off-road. This agile bike features a quick-revving 233cc engine, lightweight chassis, long-travel suspension, and styling updates including a new front fender and LED headlight. Fuel injection provides easy starting and crisp throttle response in a wide range of elevations and temperatures. The result is a consistent ride on paved streets, dirt trails and beyond.
FEATURING 233cc FUEL-INJECTED AIR-COOLED FOUR-STROKE SINGLE DUAL-SPORT CAPABILITY LONG-TRAVEL SUSPENSION ALL-DIGITAL INSTRUMENTATION
ADDITIONAL VEHICLE FEATURES Full-size wheels KX-inspired styling and ergonomics NEW LED headlight and front fender Lower seat height than KLX230 (830 mm vs 885 mm) Specifications
Wet multi-disc, manual
233cc, air-cooled, 4-stroke, SOHC 2-valve single
Fuel injection: ø32 mm x 1
Forced lubrication, wet sump
Bore X Stroke
67.0 x 66.0 mm
Perimeter, high-tensile steel
ø220 mm petal disc with single-piston caliper
Single ø265* mm petal disc with dual-piston caliper (*Non-ABS: ø240 mm)
Rake / Trail
27.5° / 116 mm
Steering Angle (L/R)
45° / 45°
Rear Suspension / Wheel Travel
New Uni Trak with adjustable spring preload / 223 mm (8.8 in)
Front Suspension / Wheel Travel
ø37 mm telescopic fork / 220 mm (8.7 in)
1,360 mm (53.5 in)
134 kg (295 lb)
830 mm (32.7 in)
210 mm (8.3 in)
LCD screen with speedometer, odometer, dual trip meters, fuel gauge, clock and indicator lamps
Dimensions (L X W X H)
2,080 x 835 x 1,110 mm (81.9 x 32.9 x 43.7 in)
The KLX230 dual-purpose motorcycle is powered by a 233cc fuel-injected, air-cooled single, tuned for low- to mid-range power.
The engine and chassis were designed together to make the KLX230 as agile and lightweight as possible.
BEYOND THE ROAD
Designed from the ground up for dirt fun. That’s why the KLX230 features long-travel suspension, front and rear disc brakes and full-size wheels.
TAKE ON THE STREET AND DIRT
Designed for the trails and tuned for on-road versatility, let the KLX230 take you to new heights with on and off-road capability.
MORE RIDERS, MORE FUN
The KLX230 S extends the playing field, allowing more riders to experience the thrill of dual-sport riding thanks to a reduced 830 mm (32.7 in) seat height (885 mm (34.2 in) on the standard model).
Call for Price Pricing excludes licensing and tax
